XNX-AMSI-NNNNN Honeywell XNX Universal Transmitter

Description XNX-AMSI-NNNNN Honeywell XNX Universal Transmitter Product Dimensions： Product Description (Detailed Explanation) The XNX Universal Transmitter is designed to provide a common interface for all gas detection needs in hazardous industrial environments. The specific configuration AMSI denotes an Aluminum housing (painted yellow) and a Standard Interface with HART® over 4-20mA communication. By using a “plug-and-play” sensor approach, the XNX allows users to monitor over 50 different flammable and toxic gases by simply swapping the sensor cartridge. Its modular design reduces the need for different types of spare parts and simplifies technician training, as the menu structure and wiring remain consistent across all gas types. Product Parameters (Technical Specifications) Parameter Category Specification Housing Material LM25 Aluminum (Epoxy Painted) Communication 3-Wire 4-20mA (Source/Sink) with HART 7.0 Input Voltage 18 to 32 VDC (24 VDC Nominal) Display Backlit LCD with Gas Concentration & Status Icons Local Interface Non-intrusive Magnetic Switches (Magnetic Wand) Cable Entries 5 x M25 (Metric) or 3/4″ NPT Operating Temp. $-40^{\circ}C$ to $ 65^{\circ}C$ Enclosure Rating IP66 / NEMA 4X Hazardous Area Certs UL, CSA, ATEX, IECEx (Class I, Div 1, Groups B, C, D) SIL Rating SIL 2 (Third-party certified) Product Advantages (Key Benefits) Universal Platform: Supports three distinct sensor technologies (Infrared, Catalytic, Electrochemical) on a single transmitter base, drastically reducing inventory costs. Non-Intrusive Operation: The transmitter can be configured, calibrated, and interrogated using a magnetic wand without ever opening the enclosure, maintaining safety in explosive atmospheres. Advanced Diagnostics: Built-in HART communication provides detailed health data, sensor life indicators, and fault codes, enabling predictive maintenance. Flexible Mounting: Features five cable entries for versatile conduit routing and optional mounting brackets for pipes or walls. Multi-Language Support: The LCD supports English, Spanish, French, German, Portuguese, Russian, and Chinese for global operational consistency. Precautions (Important Notes) Sensor Compatibility: Ensure the sensor cartridge matches the transmitter’s internal personality board (e.g., an EC personality board is required for toxic gas sensors). Earthing/Grounding: Proper grounding of the aluminum housing is essential to prevent static buildup and ensure EMC compliance. Use the internal and external earth lugs provided. Inrush Current: Be aware that certain infrared sensors (like the Searchpoint Optima Plus) combined with the XNX may have a high initial inrush current during startup; ensure the 24V power supply is adequately rated. Calibration Schedule: Even though the XNX is highly stable, regular “Bump Tests” and full calibrations are required per local safety regulations to ensure the sensor has not been “poisoned” or desensitized. Product Applications (Typical Use Cases) Oil & Gas Refineries: Detecting combustible hydrocarbons (LEL) and toxic $H_{2}S$ in processing units and tank farms. Offshore Platforms: Rugged enough to withstand salt-spray environments for fire and gas (F&G) safety systems. Chemical Plants: Monitoring specific toxic gases like Chlorine ($Cl_{2}$), Ammonia ($NH_{3}$), or Carbon Monoxide ($CO$). Wastewater Treatment: Detecting Oxygen ($O_{2}$) deficiency and Methane ($CH_{4}$) in digesters and enclosed wet wells. Power Generation: Monitoring for Hydrogen ($H_{2}$) leaks in cooling systems and $SF_{6}$ in switchgear rooms. Shipping Port: Xiamen, China Payment: Bank of Chicago, Bank of Singapore Express cooperation: fedex, DHL, UPS and your express account Service: Professional Sales provides 24 hours /7 days online service Please make an inquiry for more models： HAMAMATSU MVS-7000 Honeywell 51402645-200 Honeywell 51309204-175 Honeywell 51403776-100 Honeywell 51304465-100 Honeywell MC-PAOY22 Honeywell 51304493-250 Honeywell TC-ODK161 Honeywell 51304685-150 Honeywell 900P01-0001 Honeywell 51304453-150 Honeywell RM7838C1004 Honeywell 51305072-600 Honeywell TC-FPDXX2 Honeywell 51304511-100 Honeywell TC-PRR021 HONEYWELL 51304453-100 Honeywell 51195156-300 HONEYWELL 51304644-125 Honeywell 51400700-100 HONEYWELL 51304518-150 Honeywell 51401286-100 HONEYWELL 51304362-300 Honeywell J-DIM00 HONEYWELL 51304672-150 Honeywell J-MHM10 HONEYWELL 51304650-100 Honeywell J-MSC10 HONEYWELL 51304487-100 Honeywell 51195066-100 /HF-75632-F HONEYWELL 51304754-150 Honeywell C7027A 1049 HONEYWELL CC-PAIM01 Honeywell 51402573-150 HONEYWELL CC-PAIH01 Honeywell DC1030CR-101000-E HONEYWELL CC-PAOH01 Honeywell XC5010C HONEYWELL CC-TAOX01 Honeywell 51401437-301 HONEYWELL CC-TAIX01 Honeywell TC-LLMUX2 HONEYWELL CC-TDOB01 Honeywell FF-SB12E04K-S2 HONEYWELL CC-TDIL01 Honeywell FF-SB12R04K-S2 HONEYWELL MC-TAMR04 Honeywell TK-PRR021 HONEYWELL HONEYWELL10024/I/I Honeywell 10006/2/1 HONEYWELL 51410070-175 Honeywell DC120211101000 HONEYWELL CC-PAON01 Honeywell 51305072-100 Honeywell FF-SB14E064-S2 Honeywell 51305072-200 Honeywell TC-PRS021 Honeywell 51305072-300 Honeywell TC-CCN014 Honeywell 621-0021R Honeywell 51197593 Honeywell 620-3030 Honeywell TC-FPCXX2 Honeywell FDC220/C7027A. 1049 Honeywell TC-PCIC01K Honeywell 04973-X01-333-20-00-000-000 Honeywell TC-TCXBNC Honeywell 946 A4V 2D 2C0 380E Honeywell DC1040-CR701000-E Honeywell 51404223-001 Honeywell KSW24 Honeywell 51404203-002 Honeywell LSQA6B134 Honeywell IPC 620-15 Honeywell TK-PRS021 Honeywell 946-A4V-2D-2C0-380E Honeywell TK-CCR014 Honeywell 621-3560 Honeywell TK-IOLI01 Honeywell MU-TAIH14 Honeywell 621-0010-ARC Honeywell MU-TAOY22 Honeywell ML984 Honeywell XCL5010 Honeywell 51304337-150 Honeywell LS2D4L Honeywell TK-FTEB01 Honeywell ECEA1616R24 Honeywell 620-0083C Honeywell EC7830A1066 Honeywell 51196694-300/U1 Honeywell EC7890B1010 Honeywell 621-0020RC Honeywell LSYAC1E Honeywell C7012A1186 Honeywell FC-SDI-1624 Honeywell TC-RPCXX1 Honeywell FC-TSDI-1624 Honeywell TC-IAH161 Honeywell TC-OAV081 Honeywell 51402645-200 Honeywell 80363972-150
