AP761 – PUNTO DE ACCESO EXTERIOR WI-FI 6 HUAWEI

AP761 – Punto de Acceso Exterior Wi-Fi 6 Velocidad: 1.775Gbps. Doble banda 2.4Ghz (2×2) y 5GHz (2×2). 1 Puerto Gigabit PoE In; 1 Puerto SFP Wi-Fi standard 2.4 GHz: 802.11b/g/n/ax 5 GHz: 802.11a/n/ac/ac Wave 2/ax Installation Type Wall,Pole Optimal Signal Distance (m) 180 Max Number of Access Users 1024 Recommended Number of Access Users 120 Device Rate 1.775 Gbps Maximum number of physical ports on the entire device GE (RJ45) x 1, 10M/100M/1000M auto-sensing GE optical port (SFP) Radio number 2 Maximum channel bandwidth [MHz] Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 80 MHz Maximum transmit power 2.4G: 28 dBm (Max) 5G: 27 dBm (Max) Note: This is the total MIMO radio power, which is the same as: 2.4G: 25 dBm/chain (Max) 5G: 24 dBm/chain (Max) BLE: < 10 dBm MIMO spatial streams Radio 0 (2.4 GHz): 2×2 Radio 1 (5 GHz): 2×2 Maximum power consumption [W] 17.7 Input voltage range [V] PoE: 802.3at/af Dimensions without packaging (H x W x D) [mm(in.)] 69 mm x 200 mm x 200 mm (2.72 in. x 7.87 in. x 7.87 in.) Dimensions with packaging (H x W x D) [mm(in.)] 160 mm x 470 mm x 390 mm (6.30 in. x 18.50 in. x 15.35 in.) Weight without packaging [kg(lb)] 1.91 kg (4.21 lb) Weight with packaging [kg(lb)] 3.73 kg (8.22 lb) Long-term operating temperature [°C(°F)] –40°C to 65°C (–40°F to 149°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.) Long-term operating relative humidity [RH] 0% RH to 100% RH Radio interface Built-in directional antennas Antenna gain 2.4G: 10 dBi 5G: 11 dBi BLE: 5 dBi Operating frequency band 2.4GHz,5GHz Service port surge protection 6 kA in common mode Ingress protection level (dustproof/waterproof) IP68
