AP362E – ACCESS POINT WIFI6 AX3000 DUAL BAND HUAWEI

AP362E – AP interior Wi-Fi 6 (802.11ax) que opera en 2.4 GHz y 5 GHz (2×2 MIMO), alcanzando hasta 2.975 Gbps de velocidad de datos.   Wi-Fi standard 2.4 GHz: 802.11b/g/n/ax 5 GHz: 802.11a/n/ac/ac Wave 2/ax Installation Type Wall,Ceiling (Solid Wall/Gypsum Board/Spring Tee/Flat-Edge T-Rail/Channel Rail/Beam/Threaded Rod) Optimal Signal Distance (m) 20 Max Number of Access Users 128 Recommended Number of Access Users 100 Device Rate 2.975 Gbps Maximum number of physical ports on the entire device GE (RJ45) x 1, 10M/100M/1000M auto-sensing Radio number 2 Maximum channel bandwidth [MHz] Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 160 MHz Maximum transmit power 2.4G: 20 dBm/chain 23 dBm (combined power) 5G: 20 dBm/chain 23 dBm (combined power) MIMO spatial streams Radio 0 (2.4 GHz): 2×2 Radio 1 (5 GHz): 2×2 Maximum power consumption [W] 9.4 Input voltage range [V] PoE: 802.3af Dimensions without packaging (H x W x D) [mm(in.)] Diameter x depth: 180 mm x 35 mm (7.09 in. x 1.38 in.) Dimensions with packaging (H x W x D) [mm(in.)] 200 mm x 231 mm x 61 mm (7.87 in. x 9.09 in. x 2.40 in.) Weight without packaging [kg(lb)] 0.45 kg (0.99 lb) Weight with packaging [kg(lb)] 0.75 kg (1.65 lb) Long-term operating temperature [°C(°F)] 0°C to 40°C (32°F to 104°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.) Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing Radio interface Built-in smart antennas Antenna gain 2.4G: 4 dBi/chain (peak) 2 dBi (combined gain) 5G: 5 dBi/chain (peak value) 3 dBi (combined gain) Operating frequency band 2.4GHz,5GHz
