05701-A-0330 Honeywell Pulse preamplifier controller

Listed here are the documents that contain general information for planning and implementing control hardware and network communications in your Experion system: • Control Hardware Planning Guide – Provides general information to assist you in planning and design of control hardware in an Experion system. Control hardware includes C200 Controllers, Series A Chassis I/O and FIMs, also, all I/O families, (except Series C I/O). It includes some supervisory network considerations for general reference. • C300 Controller Guide – This guide provides information that will assist you in planning and designing activities, as well as the installation, operation, and troubleshooting of Series C300 Controllers in an Experion system. • Series C Fieldbus Interface Module (FIM) User Guide – Provides planning and implementation guide for the Series C Fieldbus Interface Module. • Fault Tolerant Ethernet Overview and Implementation Guide – Provides basic installation instructions and configuration requirements for a Fault Tolerant Ethernet (FTE) network and its components. • Fault Tolerant Ethernet Installation and Service Guide – Contains instructions for installing and configuring a Fault Tolerant Ethernet (FTE) node. The guide includes troubleshooting and service information for an FTE node. • Fault Tolerant Ethernet Bridge Implementation Guide – Provides information for implementing a Fault Tolerant Ethernet supervisory network through the FTE Bridge module. It includes module installation, configuration, operation and service data. • Process Manager I/O Troubleshooting and Maintenance Guide – Guide features notification messages (soft fail codes and hard fail codes), service procedures and parts lists for PM I/O control hardware. The following list compares previous features of the Process Manager I/O and the Series C I/O: Non-Volatile Memory: – In the PM, memory was maintained over a power cycle within the I/O card itself. – With the Series C I/O, the configuration memory information is restored from the C300 controller at power-up of the I/O Module. IOL – The Series C I/O link runs at twice the speed of the PMIO I/O Link. Each C300 I/O Link can be configured to provide Series-C or PMIO link speeds. Series C I/O fully supports HART I/O. This includes the use of Secondary HART Variables as control parameters. Separation of Primary from Secondary modules: – In the PM, the Primary and Secondary I/O Electronics modules could be separated, placed in different cabinets, and/or powered by different power systems. – Series C I/O does not have this capability. Series C permits Zone 2 mounting of the Controller and I/O In PMIO, the configuration memory is maintained only if a battery backup is installed. The Experion Series C PIM is an interface between C300 Controller that enables high-accuracy pulse counting of pulse streams from rotating machinery such as turbines, flow meters, and densitometers. High-accuracy and repeatable measurement capability make the PIM well suited for metering and custody transfer applications. The PIM has eight input channels. Out of the eight channels, some may be single consuming one channel or dual consuming 2 adjacent channels. The last 2 channels (channel 7 and channel 8) can also be configured as distinct Fast Cutoff using the two output channels on the module. Each input channel has a 32-bit counter to perform pulse counting and frequency calculation. In addition, when these channels are configured as single input channels, these eight channels also have a second 32-bit timer for pulse period and pulse width measurement. 2.3.1 Features of PIM The following are some of key the features of PIM. Supports IOM redundancy. Supports redundant module communications with the controller via IO link. Supports simulation with SIM-C300 – The input value can be substituted by a program and/or UniSim using the SIMVALUE parameter. Supports high accuracy frequency, period, and pulse width measurement. Provides hardware support for Meter Suite applications. Provides connections to power field devices or pulse pre-amplifiers. Supports pulse multiplexing that enables good pulses from a dual pulse input pair to be copied to the Prover output interface. Supports Dual Pulse Integrity in accordance with ISO6551:1996 Level A, which is required to support interfacing of custody transfer meters with pulse outputs. Provides the flexibility of configuring the eight input channels as single input, dual input, or a combination of both single and dual input channels . For example you can configure the channels as; – 2 single input channels, 3 dual input channels or – 6 single input channels, 1 dual input channels. For information on PIM specifications, refer to the Specifications document available on the Honeywell Online Support site.   The prices of all products of Zhangzhou Fengyun may fluctuate at any time. The specific price is subject to the customer service quotation. Please confirm the model, product, price and other details with the customer service before placing the order. Second-hand and brand-new products are sold in the store. Please contact the customer service for details.   Recommended HONEYWELL related models： CC-MCAR01 HONEYWELL CC-MCAR02 HONEYWELL CC-PAIH01 HONEYWELL CC-PAIH02 HONEYWELL CC-PAIH51 HONEYWELL CC-PAIM01 HONEYWELL CC-PAIN01 HONEYWELL CC-PAIX01 HONEYWELL CC-PAIX02 HONEYWELL CC-PAOH01 HONEYWELL CC-PAON01 HONEYWELL CC-PAOX01 HONEYWELL CC-PCF901 HONEYWELL CC-PCNT01 HONEYWELL CC-PCNT02 HONEYWELL CC-PCNT02 51454551-275 HONEYWELL CC-PDIL01 HONEYWELL CC-PDIL51 HONEYWELL CC-PDOB01 HONEYWELL CC-PDOD51 HONEYWELL CC-PFB401 HONEYWELL CC-TAID01 HONEYWELL CC-TAID11 HONEYWELL CC-TAIM01 HONEYWELL CC-TAIN01 HONEYWELL CC-TAIX01 HONEYWELL CC-TAIX11 HONEYWELL CC-TAON01 HONEYWELL CC-TAOX01 HONEYWELL CC-TAOX11 HONEYWELL CC-TAOX61 HONEYWELL CC-TCF901 HONEYWELL CC-TCNT01 HONEYWELL CC-TDIL01 HONEYWELL CC-TDIL11 HONEYWELL CC-TDIL51 HONEYWELL CC-TDIL61 HONEYWELL CC-TDOB01 HONEYWELL CC-TDOB11 HONEYWELL CC-TDOD51 HONEYWELL CP-EXPIO HONEYWELL DC3200-CE-200R-200-00000-00-0 HONEYWELL FC-DCOM-232/485 HONEYWELL FC-PSU-UNI2450U V1.0 HONEYWELL FC-QPP-0002 HONEYWELL FC-SAI-1620M HONEYWELL FC-SAI-1620M V1.4 HONEYWELL FC-SCNT01 HONEYWELL FC-SDI-1624 HONEYWELL FC-SDIL-1608 HONEYWELL FC-SDO-0824 HONEYWELL FC-SDO-0824 V1.3 HONEYWELL FC-SDOL-0424 HONEYWELL Show More Show Less
