HONEYWELL CC-TAIN01 | Analog Input Termination Assembly Series C

Description Key Technical Specifications Parameter Specification Part Number CC-TAIN01 Product Type Termination Assembly Series Experion Series C Compatibility CC-PAIX01, CC-PAIH01, CC-PAON01 analog input modules Channels 8 analog inputs Termination Type Screw terminals (standard) Wire Size 12-24 AWG typical Field Power 24V DC distribution (optional) Isolation Provided by I/O module Indicators None (passive device) Mounting DIN rail (35 mm) Hot Swap Supported (module swaps while TA remains) Operating Temp -40°C to 70°C Dimensions Standard Series C TA footprint Condition New Surplus (Original Packaging)   Product Introduction The HONEYWELL CC-TAIN01 is a termination assembly (TA) for analog input modules in the Experion Series C I/O system. It provides the physical interface between field wiring and the electronic I/O module (such as CC-PAIX01 or CC-PAIH01). The TA mounts on DIN rail and remains in place when the electronics module is removed, enabling hot-swap capability. The CC-TAIN01 features 8 channels of screw terminals for field connections, with optional 24V DC distribution for loop-powered transmitters. It accepts wire sizes up to 12 AWG and is rated for industrial environments. This unit is new surplus, factory-sealed in original Honeywell packaging. Series C components are widely deployed in process industries; contact us for current stock and firm pricing.   Frequently Asked Questions (FAQ)   Q: What is a termination assembly (TA) and why is it used? A: The HONEYWELL CC-TAIN01 is a passive wiring interface. It: Mounts on DIN rail Provides screw terminals for field wiring Connects to the electronic I/O module via a backplane connector Stays in place when the electronics module is removed This separation allows: Hot-swapping of electronics without rewiring Pre-wiring of cabinets before module installation Simplified troubleshooting (swap modules, keep wiring) Field wiring isolation from sensitive electronics The TA is the “wiring side” of the I/O system; the module is the “electronics side.” Q: What analog input modules are compatible with CC-TAIN01? A: The CC-TAIN01 is designed for Honeywell Series C analog input modules, including: CC-PAIX01 (standard analog input) CC-PAIH01 (HART analog input) CC-PAON01 (analog output, note: output uses different TA typically) Other 8-channel analog input modules in the Series C family Always verify compatibility with your specific module. The CC-TAIN01 is for analog input; analog output modules use different termination assemblies (e.g., CC-TAON01). Check your module’s documentation. Q: Does the CC-TAIN01 provide loop power for transmitters? A: The HONEYWELL CC-TAIN01 has provisions for 24V DC distribution, but whether loop power is provided depends on: The I/O module (e.g., CC-PAIX01 requires external power) Field wiring configuration Optional power distribution terminals on the TA The TA itself is passive—it doesn’t generate power. It may have terminals for connecting field power, but the power source is external. For loop-powered transmitters using modules like CC-PAIH01, the module may provide power; the TA just passes it through. Q: Can I wire the before installing the I/O module? A: Yes, absolutely. That’s a key feature of Series C I/O. You can: Mount the on DIN rail Run and terminate all field wiring Test wiring continuity Later install the electronic module (e.g., CC-PAIX01) This allows cabinet fabrication and wiring to proceed independently of module availability. It also simplifies replacement—pull the old module, leave the TA, plug in the new one. Q: What’s the difference between and CC-TAIN02? A: The suffix (-01 vs -02) typically indicates: Different termination type (screw vs compression) Different channel count Different features (fusing, power distribution) is the standard 8-channel screw terminal version. CC-TAIN02 may be compression terminals or have additional features. Always match the exact part number from your existing system. The TA must match both the module type and the wiring method used in your cabinet. Q: Is the hot-swappable? A: The TA itself is not swapped—it’s permanently mounted. The electronic module (e.g., CC-PAIX01) is hot-swappable. The HONEYWELL CC-TAIN01 stays in place during module replacement. This is the entire point of the TA design: field wiring never moves, modules can be swapped live. Q: What wire size can I use with? A: The accepts wire sizes from 12-24 AWG typical. For specific torque ratings and wire strip lengths, consult the Honeywell installation manual. In practice: 14-18 AWG is common for analog signals Use ferrules on stranded wire for reliable connections Don’t overtighten screws—follow recommended torque   Q: What’s the typical failure mode for termination assemblies? A: TAs are passive—they rarely fail electrically. Common issues: Loose connections from vibration or improper tightening Corrosion in harsh environments (chemical plants, coastal) Mechanical damage to terminals or housing Wire breakage at termination due to strain The HONEYWELL CC-TAIN01 itself is robust. Most “TA problems” are actually wiring issues. If you suspect a TA fault, check for loose screws, corrosion, or damaged terminals. The TA can be replaced without removing field wiring (if you disconnect wires first, then reconnect to new TA). Q: Does the require configuration? A: No. The is purely passive—no electronics, no configuration. It simply connects field wires to the I/O module. All configuration is done in the module and the C300 controller. Q: Can I use with third-party wiring? A: Yes, the accepts standard industrial wiring. Use: Appropriate wire gauge Shielded twisted pair for analog signals Proper grounding practices Wire ferrules for stranded conductors The TA doesn’t care what brand of wire you use, as long as it meets specifications. Follow good wiring practices for analog signals to avoid noise and ground loops. Q: What’s the difference between and CC-TAIN11? A: The numbering indicates: : Standard screw terminals CC-TAIN11: May be compression terminals or high-density version Honeywell uses different suffixes for different termination styles. Always verify with your system documentation. The wrong TA may not fit your module or may not match your field wiring method. Q: How do I identify the channel numbers on? A: The is clearly marked with channel numbers (1-8) corresponding to the I/O module’s channels. The TA also has labels for field power ( 24V, 0V) if used. Refer to the Honeywell installation drawing for your specific wiring scheme. In Series C, channel mapping is 1:1 between TA terminals and module channels. Q: Can the be mounted in a hazardous area? A: The TA itself is passive, but it must be mounted in an appropriate enclosure for the area classification. The is general-purpose (non-hazardous area). If field wiring enters a hazardous area, you must use appropriate barriers and follow entity parameters. The TA does not provide intrinsic safety—it’s just a connection point. KeTop-T40-001/58599/10 PLC 2711P-K6C20D PLC FOXBORO-H92HP PLC 2711P-B15C4A8 PLC max-4/11/03/016/08/1/0/00 PLC Email: [email protected] Phone: 86 15340683922 Sales:Wu Jiedong Our products are guaranteed for 1 year, with new and original production stopped and imported spare parts. All prices listed on the official website are subject to confirmation by contact: Wu Jiedong (manager). Our product: brand new original packaging Our warranty: All new or repaired parts have a 12 month warranty period beginning Our payment: 100% telegraphic transfer of inventory items before shipment, conditions can be proposed! If you have any downtime spare parts that you cannot find, please feel free to call or use email to contact me. If there are issues that the product cannot solve, please contact me. Product prices can be negotiated. Please do not consider contacting me!
